Package URL for storing API artifacts | Simplified Dependency Management

Learn how Package URL (PURL) standardizes and simplifies API dependency management across different ecosystems. This guide shows how to reduce manifest size and improve readability in API repositories

Posted Updated
Preview Image
By Pavel Bodiachevskii
1 min read
Package URL for storing API artifacts | Simplified Dependency Management

While working on unifying the storage of required packages for APIs, I found an interesting standard called PURL (Package URL)

What is PURL?

Package URL (PURL) is a standardized way to identify and locate software packages across different ecosystems. It provides a consistent format for referencing packages regardless of their origin or package manager. The PURL specification defines a string format that contains all the necessary components to precisely identify a package:

1

pkg:type/namespace/name@version?qualifiers#subpath

Benefits of PURL

  • Uniformity: Provides a consistent way to reference packages across different ecosystems (npm, Maven, PyPI, etc.)
  • Simplicity: Easy to read, parse, and construct
  • Flexibility: Works with various package managers and repositories
  • Interoperability: Facilitates communication between different systems and tools

In the context of API management, PURL allows us to significantly reduce the API manifest size and improve readability:

From this

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18

urn: com.myCompanyName:asyncapi:chat-api-gateway:2.34.0
cycle: Release
contract:
  $ref: 'https://api-hub.com/apis/asyncapi/5a0052fd-fd49-4eb1-a257-1f246906a0da'
artifacts:
  maven:
    - language: java
      framework: any # spring-boot | quarkus | micronaut
      dependency: # com.github.myCompanyName:chat-api-gateway:2.34.0
        groupId: com.myCompanyName
        artifactId: chat-api-gateway
        version: 2.34.0
  npm:
    - language: typescript
      dependency: # "@myCompanyName/chat-api-gateway": "2.34.0"
        groupId: myCompanyName
        artifactId: chat-api-gateway
        version: 2.34.0

To this

1
2
3
4
5
6
7

urn: com.myCompanyName:asyncapi:chat-api-gateway:2.34.0
cycle: Release
contract:
  $ref: 'https://api-hub.com/apis/asyncapi/5a0052fd-fd49-4eb1-a257-1f246906a0da'
artifacts:
  - pkg:maven/com.myCompanyName/chat-api-gateway@2.34.0
  - pkg:npm/@myCompanyName/chat-api-gateway@2.34.0

Quick reminder, that by treating APIs as full-fledged dependencies with standardized references like PURL, teams can manage their API dependencies with the same rigor and tooling as they do with their software libraries

Specifications, API
asyncapi openapi
